型号：6203
轴承型号Bearing NO. | 外形尺寸(mm)Shape Dimension(mm) | 钢球Steel Ball | 基本额定负荷(KN)basic Load Rating(KN) | 极限转速 (转/分) Max Speed(rpm) | 重量Weight(kg) | ||||||||||
Bore d | Outer Diameter D | Width B | Radius r min | Size mm | Quantity NO. | Dynamic Cr | Static Cor | 脂润滑 Grease | 油润滑 Oil | ||||||
mm | inch | mm | inch | mm | inch | mm | inch | ||||||||
6200 | 10 | 0.3937 | 30 | 1.1811 | 9 | 0.3543 | 0.6 | 0.0236 | 4.763 | 8 | 5.1 | 2.38 | 19000 | 26000 | 0.028 |
6201 | 12 | 0.4724 | 32 | 1.2598 | 10 | 0.3937 | 0.6 | 0.0236 | 5.953 | 7 | 6.82 | 3.05 | 18000 | 24000 | 0.034 |
6202 | 15 | 0.5906 | 35 | 1.3780 | 11 | 0.4331 | 0.6 | 0.0236 | 5.953 | 8 | 7.65 | 3.72 | 17000 | 22000 | 0.043 |
6203 | 17 | 0.6693 | 40 | 1.5748 | 12 | 0.4724 | 0.6 | 0.0236 | 6.747 | 8 | 9.58 | 4.47 | 16000 | 20000 | 0.062 |
6204 | 20 | 0.7874 | 47 | 1.8504 | 14 | 0.5512 | 1 | 0.0394 | 7.938 | 8 | 9.88 | 6.2 | 14000 | 18000 | 0.102 |
6205 | 25 | 0.9843 | 52 | 2.0472 | 15 | 0.5906 | 1 | 0.0394 | 7.938 | 9 | 10.78 | 6.98 | 12000 | 16000 | 0.12 |
6206 | 30 | 1.1811 | 62 | 2.4409 | 16 | 0.6299 | 1 | 0.0394 | 9.525 | 9 | 14.97 | 10.04 | 9500 | 13000 | 0.19 |
6207 | 35 | 1.3780 | 72 | 2.8346 | 17 | 0.6693 | 1.1 | 0.0433 | 11.112 | 9 | 19.75 | 13.67 | 8500 | 11000 | 0.27 |
